Portable Hand Manual Forklift Price

Model

CPC35

Power

柴油/Diesel

Rated lifting load

KG

3500

Load center distance

mm

500

Driving mode

座驾式/Seat driving

With fork

   mm

3930

Without fork

2690

Width

1210

Height when the mast not raised

2130

Overhead guard height

2100

Wheelbase

1700

Front overhang

479

Rear overhang

520

Minimum ground clearance

110

No-load maximum lifting height

两级4000

Free lifting height

160

Minimum turning radius (outer side)

2240

Mast tilt angle (front/rear)

（^°）

6°/12°

No-load maximum lifting speed

mm/s

505

Full-load maximum lifting speed

485

No-load maximum working speed

Km/h

20

Full-load maximum working speed

18

Full-load maximum gradeability

％

20

Forklift weight under standard no-load condition

Kg

4450

Tire no. (F/R)

2/2

Tire type (F/R)

充气胎/Air inflation tire

Tire size (F)

28x9-15

Tire size (R)

6.50-10

Brake/service brake

动力制动—踏板/Power brake-pedal

Parking brake

机械-手动式/Machenical-manual

Battery voltage/capacity

V/Ah

12/80

Engine model

新柴（全柴）C490BPG/xinchai（quanchai）

Engine fuel tank capacity

L

60

Transmission box

机械换挡/Mechanical shift

Number of gear lever

2
